Equipment Main performance

1. Windows 10 operating system, control system adopts Huajian's proprietary intellectual property Delta5.0

Window 10 operation system to control machine base on own R&D Delta 5.0

2. Double axis synchronous processing or single axis large-size processing, multi-layer boards and double drilling boards do not require the use of pads:

Dual-axis synchronous processing or single-axis large-size processing, no need for spacer

platesformultilayer boards and double-driled boards

3. The machine tool and motion axis reference platform are all made of natural black granite, with high precision and minimal susceptibility to external environmental changes

Machine frame and motion axis reference plane made entirely of natural black granite

providing high precision and minimal sensitivity to external environment changes

4. The Z-axis transmission adopts ball screws from world-renowned Japanese NSK or THK companies

The Z-axis drive uses ball screws from world-renowned brands. NSK or THK

5. Guided by THK from Japan and Schneberg linear guides from Germany

Guiding system use THK brand from Japan and Germany Schneeberager for liner quides

6. Air floating spindle 200000 revolutions per minute

Drilling spindle speed:200K.rpm air-floating spindle.

7. Automatic measurement of tool length, contact type tool breakage detection

Automatic measuring the length of tool and contact-based tool breakage detection

8. Board detection function, realizing automatic processing and automatic cycle drilling depth control (optional).

Board detection function, to achieve automatic processing and automatic circulation drilling control (optional)

9. It can directly drill 6.5-13mm ultra large knives in one go.

Machine can to drilled out diameter6.5-13mm directly.
