Equipment Main performance

1、Window10操作系统，控制系统采用华建自主知识产权Delta5.0

Window 10 operation system to control machine base on own R&D Delta 5.0

2、双轴同步加工或单轴大尺寸加工，多层板、二钻板无需使用垫板:

Dual-axis synchronous processing or single-axis large-size processing, no need for spacer

platesformultilayer boards and double-driled boards

3、机床及运动轴基准平台全部为天然黑色花岗石，精度高，受外界环境变化小

Machine frame and motion axis reference plane made entirely of natural black granite

providing high precision and minimal sensitivity to external environment changes

4、Z轴传动采用世界[敏感词]产品日本NSK或THK公司的滚珠丝杆

The Z-axis drive uses ball screws from world-renowned brands. NSK or THK

5、导向采用日本THK和德国施耐博格直线导轨

Guiding system use THK brand from Japan and Germany Schneeberager for liner quides

6、气浮主轴20万转每分钟

Drilling spindle speed:200K.rpm air-floating spindle.

7、自动测量刀具长度，接触式断刀检测

Automatic measuring the length of tool and contact-based tool breakage detection

8、板面探测功能，实现自动加工和自动循环钻深控制(选配)。

Board detection function, to achieve automatic processing and automatic circulation drilling control (optional)

9、可以直接实现6.5-13mm的超大刀直接一次钻。

Machine can to drilled out diameter6.5-13mm directly.
